The CompuLab EDGEAI-ORN-CNA4-N256-FGMSL-XJP62-P60 is a compact, fanless Edge AI computer designed for computer vision, machine vision, robotics, industrial inspection and other camera-based AI applications. It is powered by the NVIDIA Jetson Orin Nano 4GB and supports up to 34 TOPS of sparse INT8 AI performance when operated with the supported JetPack 6.2 Super Mode. A 256GB NVMe SSD with Jetson Linux JetPack 6.2 pre-installed provides a ready-to-use Linux platform for local AI inference, application development and deployment at the edge.

This configuration includes a four-channel GMSL2 camera interface with Power over Coax through four FAKRA Z connectors. Compatible GMSL2 cameras can transmit video data and receive power through the same coaxial cable, reducing cabling requirements and supporting reliable camera connections in industrial and mobile installations.

The EdgeAI-ORN provides extensive connectivity for integration with cameras, sensors, controllers and network infrastructure. Available interfaces include USB 3.2, USB 2.0, HDMI, 2.5 Gigabit Ethernet, Gigabit Ethernet, isolated serial communication, CAN bus and digital GPIO. TPM 2.0 supports hardware-based security functions, while the wide 9–36V DC input makes the system suitable for industrial equipment, autonomous machines and vehicle-based installations.

Like many of CompuLab’s industrial computers, this EdgeAI-ORN configuration uses a full-coverage passive heatsink extending across the top and sides of the enclosure. The fanless design supports quiet, low-maintenance operation without moving cooling components.

Key features

• Up to 34 TOPS sparse INT8 AI performance
• 256GB M.2 NVMe SSD with Jetson Linux JetPack 6.2 pre-installed
• 4 × GMSL2 camera inputs with Power over Coax via FAKRA Z connectors
• 4 × USB 3.2, 2 × USB 2.0 and HDMI
• 1 × 2.5GbE, 1 × Gigabit Ethernet and industrial serial, CAN and GPIO interfaces
• TPM 2.0 hardware-based security
• Full-coverage passive cooling and wide 9–36V DC input
• 60W external power supply included
• Five-year manufacturer warranty
